Original Renault CAN CLIP interface: Confirmed

I showed: that is the GENUINE Renault can clip diagnostic instrument

original-renault-can-clip-device-1 Original Renault CAN CLIP interface: Confirmed Drivers Software ^(https://i2.wp.com/4.bp.blogspot.com/-s_WliUd3b6o/WZOvbNypcvI/AAAAAAAAG8g/wTTxuGjD0-gnmIlunFukVxR5zYhp0aMOQCLcBGAs/s1600/original-renault-can-clip-device-1.JPG?ssl=1)original-renault-can-clip-device-2 Original Renault CAN CLIP interface: Confirmed Drivers Software ^(https://i2.wp.com/2.bp.blogspot.com/-3bZtzxBlSjY/WZOvbfTf12I/AAAAAAAAG8k/s55XeG3-8HE5pghNTi-p-zPCkZByz_SaACLcBGAs/s1600/original-renault-can-clip-device-2.JPG?ssl=1)

original-renault-can-clip-interface%2B%25281%2529 Original Renault CAN CLIP interface: Confirmed Drivers Software

original-renault-can-clip-interface%2B%25282%2529 Original Renault CAN CLIP interface: Confirmed Drivers Software

original-renault-can-clip-interface%2B%25283%2529 Original Renault CAN CLIP interface: Confirmed Drivers Software

original-renault-can-clip-interface%2B%25284%2529 Original Renault CAN CLIP interface: Confirmed Drivers Software

original-renault-can-clip-interface%2B%25285%2529 Original Renault CAN CLIP interface: Confirmed Drivers Software

original-renault-can-clip-interface%2B%25286%2529 Original Renault CAN CLIP interface: Confirmed Drivers Software

original-renault-can-clip-interface%2B%25287%2529 Original Renault CAN CLIP interface: Confirmed Drivers Software

original-renault-can-clip-interface%2B%25288%2529 Original Renault CAN CLIP interface: Confirmed Drivers Software

 cypress on ISO pcb

renault-can-clip-cypress-on-ISO-and-CAN-PCB-1 Original Renault CAN CLIP interface: Confirmed Drivers Software

 cypress on CAN pcb

renault-can-clip-cypress-on-ISO-and-CAN-PCB-2 Original Renault CAN CLIP interface: Confirmed Drivers Software
1:1 clone of the unique:
High quality A+++ Renault CAN CLIP clone ^(http://www.eobdtool.co.uk/wholesale/renault-can-clip-diagnostic-interface-lastest-version.html)
renault-can-clip-an2135sc-chip Original Renault CAN CLIP interface: Confirmed Drivers Software

renault-can-clip-an2135sc-pcb-1 Original Renault CAN CLIP interface: Confirmed Drivers Software

renault-can-clip-an2135sc-pcb-2 Original Renault CAN CLIP interface: Confirmed Drivers Software

Renault CAN CLIP worked with Nissan Consult software

Hello G.A guys,
Listed here are a PCB CANCLIP interface ( bluetooth) identified by way of clip software with the reference 926573 and will paintings with the NISSAN CONSULT software.

renault-can-clip-work-with-nissan-consult-iii%2B%25281%2529 Renault CAN CLIP worked with Nissan Consult software Drivers Software

 This interface is rather other than obdstart

CAN digital board :

renault-can-clip-work-with-nissan-consult-iii%2B%25282%2529 Renault CAN CLIP worked with Nissan Consult software Drivers Software

renault-can-clip-work-with-nissan-consult-iii%2B%25283%2529 Renault CAN CLIP worked with Nissan Consult software Drivers Software

 ISO digital board :

renault-can-clip-work-with-nissan-consult-iii%2B%25284%2529 Renault CAN CLIP worked with Nissan Consult software Drivers Software

renault-can-clip-work-with-nissan-consult-iii%2B%25285%2529 Renault CAN CLIP worked with Nissan Consult software Drivers Software

 This interface is down, the fairway ISO LED does no longer remove darkness from ! !

Searching for somewhat extra meadows, the use of a multimeter we will see that the ISO LED is managed
immediately from microprocessor on CAN digital board by means of part and 2×35 issues connector. So I redid the welds of
those parts.

Some other level at the CAN digital board on the voltage converter 3.3Vdc -> 5Vdc ( LTC1871 ),we discovered an influence MOSFET
in case SOIC8 . I suppose this is a FDS7760A following the LTC1871 datasheet (the reference of the part being buffed ! ) Right here:

renault-can-clip-work-with-nissan-consult-3%2B%25281%2529 Renault CAN CLIP worked with Nissan Consult software Drivers Software

 This part is cooled during the floor airplane ! This is the reason it’s rather over- prime.
Additionally, a drain tabs ( on this case the pin5 ) isn’t welded ? ?
So I resoldered this part correctly, caring for the neatly -plated to verify touch with the runway beneath
thereof.

After a check desk with a 12Vdc energy provide , the fairway ISO LED lighting once more .

Reputation of the USB motive force within the instrument supervisor :

renault-can-clip-work-with-nissan-consult-3%2B%25282%2529 Renault CAN CLIP worked with Nissan Consult software Drivers Software

 Updating firmware of the probe :

renault-can-clip-work-with-nissan-consult-3%2B%25283%2529 Renault CAN CLIP worked with Nissan Consult software Drivers Software

 Then route car, for an actual check on a multiplex community :

renault-can-clip-work-with-nissan-consult-3%2B%25284%2529 Renault CAN CLIP worked with Nissan Consult software Drivers Software

 Enjoying a default at the parking brake :

renault-can-clip-work-with-nissan-consult-3%2B%25285%2529 Renault CAN CLIP worked with Nissan Consult software Drivers Software

And now a brand new probe repaired.

hyperlinks :
Voltage converter datasheet : LTC1871EMS ( LTSX marking code)

http://pdf1.alldatasheet.com/datasheet-pdf/view/82475/LINER/LTC1871EMS.html

MOSFET datasheet : FDS4072N3 ( wager the reference part being buffed !)
http://pdf.datasheetcatalog.com/datasheet/fairchild/FDS7760A.pdf

NO ONE BUT YOURSELF HAVE TO TAKE RESPONSIBILITY OF WHAT YOU’LL TRY.

for those who aren’t supplied with tech or wisdom, or fail to make Renault CAN CLIP interface paintings with Nissan Consult software, please cross to Renault CAN CLIP and Nissan Consult iii 2 in 1 diagnostic interface ^(http://www.eobdtool.co.uk/wholesale/renault-can-clip-and-nissan-consult-l-2-in-1-tool.html):

renault-can-clip-and-consult-3-diagnostic-tool Renault CAN CLIP worked with Nissan Consult software Drivers Software
supply: http://www.eobdtool.co.united kingdom/wholesale/renault-can-clip-and-nissan-consult-l-2-in-1-tool.html ^(http://www.eobdtool.co.uk/wholesale/renault-can-clip-and-nissan-consult-l-2-in-1-tool.html)

it is just 120 euro (stored so much), operating nice as Renault can clip ^(http://www.eobdtool.co.uk/wholesale/renault-can-clip-diagnostic-interface-lastest-version.html) and Nissan seek the advice of 3
